Machining / Balancing / Driveshaft Manufacturing

   - Clay's Industrial Supply strives to be your first choice when it comes to Machining, Balancing            and Driveshaft Manufacturing. We take pride in our work, and will use the best quality                material on the market to ensure you are getting the highest quality product every time.

SCHENCK BALANCER

Machine specifications:



ROTOR MASS LIMITATIONS

Max weight (6,500 Lbs)

Max sensitivity per plane: 3.75 gram-inch above (100rpm)

0.75 gram-inch above (400rpm)

0.15 gram-inch above (900rpm)

0.03 gram-inch above (1,800rpm)

Instrumentation speed range (100 to 5,000 rpm)

Unbalance reduction ratio: Up to 95%

ROTOR DIMENSIONS

Max diameter over machine bed: 63 Inches

Rotor belt-drive diameter range: 1.2 to 24 Inches

Max distance between support bearing centerlines: 109 Inches

Minimum distance between support bearing centerlines with: belt-drive inboard (5.5) inches. Belt-drive outboard (2.75) inches

Journal diameters accommodated: 0.6 to 4.75 inch, 4.75 to 9.5 inch

HAAS ST-30

Machine specifications:



Slant bed, horizontal CNC lathe.

Max swing diameter is 31.75 inches.

Max turn diameter is 21 inches.

Max turn length is 26 inches.

Chuck is 15 inches in diameter.

Through spindle diameter is 3.58 inches.

Max work piece weight (one-side support) 500lbs

Max work piece weight (between centers) 900lbs

Spindle speed range 40-3400 rpm (infinitely variable)

Number of controlled axis 2 (X,Z)

Programmable tailstock.

Turret has 12 tools.

The controller is equipped with G-code direct capabilities.

HAAS TL-3W

Machine specifications:



Flat bed, hybrid, semi-conversational CNC Lathe.

Max swing diameter is 30 inches.

Max turn diameter over cross slide is 18 inches.

Max turn length is 48 inches.

Chuck is 15 inches in diameter.

Through spindle diameter is 3.5 Inches.

Spindle speed range 40-1500 rpm (infinitely variable)

Steady rest diameter range from 0.5 inches to 9.0 Inches.

Number of controlled axis 2 (X,Z) Single position tool post.

The controller is semi-conversational.

HAAS TM-3

Machine specifications:



CNC vertical mill.

X axis travel is 40.0 Inches.

Y axis travel is 20.0 Inches.

Z axis travel is 16.0 Inches.

Maximum rpm is 6000.

12 tool turret capacity.

Maximum weight on table (evenly distributed) 1000 pounds.

CAT40 spindle.

Maximum cutting feed rate 200 inches per minute.

JOHNFORD DMC-1600H

Machine specifications:

Double column,vertical mill.

Table size is 66.9 inches by 43.3 inches.

X axis travel is 63.0 inches.

Y axis travel is 51.0 inches.

Z axis travel is 31.0 inches.

Machine is equipped with a 4th-axis and footstock.

4th-axis center height is 8.5 inches.

4th-axis through bore is 4.0 inches.

4th-axis chuck diameter is 12.0 inches.

CAT-50 spindle taper Through-coolant spindle.

Maximum spindle speed is 6000rpm with Hi-Low gear.

24 pocket arm type, automatic tool changer.

13,200 lbs table load capacity.

The controller is Fanuc Series oi-model D.



PRO-KING MEGA BORE

Machine specification:

Horizontal conventional manual lathe.

Max swing diameter is 70 inches.

Max swing over carriage is 58 inches.

Bed length: 4 meters.

X axis travel 26 inches.

Z axis travel 120 inches.

Headstock through bore 21 inches.

Double 46 inch diameter chucks.

Steady rest diameter range from 6 inches to 25 inches.

Variable rpm turning abilities.

Spindle speed range 15-350 rpm.

HYUNDAI WIA L7000LMA

Machine specifications:



Horizontal, slant bed, live tool, CNC turning center.

Swing over the bed is 41 inches.

Max turn length is 120.0 inches.***

Max turn diameter is 36.0 inches.

Chuck is 24 inches in diameter.

Through spindle diameter is 6.5 inches.

Max work piece weight one-side support, 750 pounds.

Max work piece weight between centers is, 4000 pounds Programmable tailstock.

Programmable steady rest A maximum clamping diameter of 13.75 inches.

A minimum clamping diameter of 3.3125 inches.

Spindle speed range 40-1500 rpm (infinitely variable)

Driven tool speed range 45-3000 rpm (infinitely variable)

Number of controlled axis 3 (X,Z,C)

C-Axis controlled angle is 360 degrees in 0.001 degree increments.

Turret has 12 tools. All positions are driven tool compatible.

The controller is Fanuc Series 32i-Model A.

Driveshaft Manufacturing & Balancing Equipment

Couplers for all series of driveline.

Large inventory of 1710, 1810 and SPL 250
